12 Volt Alternator Conversion Kit Fits IH Fits Cub & Fits Cub Lo Boy

One New Aftermarket Replacement 6 to 12 Volt Conversion Kit
Fits IH Models:
Fits Cub & Fits Cub Loboy
Kit Contains:
(1) Mini Alternator w/ Pulley
12 Volt, 35 Amp
1 Wire Hook-up
4-1/2″ Housing Diameter
2-3/4″ Pulley OD
1/2″ Belt Width
Works with Magneto or Distributor Ignitions
For Negative Ground Systems Only
Note: (Simple 1 wire alternator hook up) Run a wire from the alternator through the ammeter to positive side of battery. Must rev the engine to 800 – 850 RPM in order to self-excite.
Replaces Part Number: 100211-1660
(1) 2-pc Alternator Bracket Kit
Must use with ABC3551 alternators only.
Can re-use your existing belt (the belt will ride over the pulley but still work), OR order #ABC2315 pulley for wider belt width.
Direct bolt on, no cutting on hood!
**DOES NOT FIT 154, 185, 184 Loboy**
(1) Internal Resistor Coil
6V W/O Resistor,
12V W/ Resistor
