12V DC Electric Winch with Steel Rope: 7/32″ Diameter x 50′ Length – 3,500 lbs Load Capacity, 10802013 XP-35

Standard duty ATV winch with 7/32″ AWR steel rope, Roller Fairlead, and 3,500 lb. pulling capacity; Ideal for Large ATV and some SxS UTV.
Large Diameter 12V DC Permanent Magnet Motor provides maximum torque for more pulling power. Gear Ratio: 163:1
Wireless Remote Control and Handlebar Switch included to provide best control for all winching situations.
Automatic Spring Brake holds full rated load.
Ergonomic External Clutch Dial allows easy operation in tight spaces.
Features IP68-rated waterproof construction and corrosion-resistant design ensures winch is built to last.
Please confirm the fit of mounting plate before purchase, Mounting Bolt Pattern: 4.87″x 2.99″. SPECIFICATIONS
Rated Line Pull
3,500 lbs. (1,588kg)
Motor
12V DC Permanent Magnet
Remote Control
Wireless Remote
Geartrain
3-Stage Planetary
Gear Ratio
163:1
Brake
Spring Brake
Rope
7/32IN??50FT Steel
Fairlead
Roller
