5LP-84700-11-00 5LP-84702-30-00 Rear Brake Taillight Bracket For Yamaha

Premium Quality Replacement Part
Rear Brake Taillight with Bracket Assembly
For Yamaha Models:
Raptor 660R YFM660R 2002-2005
Order Includes:
1 x Tail Light | 5LP-84700-11-00 5LP-84700-10-00
Length: 156.0 mm | 6.14″
Width: 102.0 mm | 4.01″
Mounting Hole Distance: 114.0 mm | 4.48″
1 x Bracket | 5LP-84702-30-00
Length: 200.3 mm | 7.88 ”
Width: 62.7 mm | 2.46″
Height: 78.12mm | 3.07 ”
Diameter: 34.85 mm |1.37 ”
Bracket Includes:
2 x Bolt Flange | 95807-06030-00 95817-06030-00
2 x Washer | 90201-06074-00
2 x Grommet | 90480-15528-00
2 x Collar | 90387-075H4-00
2 x Grommet | 90480-14555-00 90480-14229-00
1 x Collar | 90387-075U2-00
2 x Collar | 90387-07391-00
**
