Champion 3000-lb. ATV/UTV Winch Kit, BLACK,RED

Powerful ?C 3000 lb. max rated line pull and 1 HP permanent magnet motor
Bonus Accessories ?C Roller fairlead, mounting channel, handle bar mounted remote control
49 ft. super duty aircraft cable with rugged, latched clevis hook
Efficient planetary gear and dynamic braking systems
Champion Support – 2 year limited warranty with FREE lifetime technical support Champion Power Equipment is one of the market leaders in power generation equipment. Champion has years of experience providing dependable and durable power products designed and engineered in the US for the North American and world markets.
Champion 3000-lb. ATV/UTV Winch Kit
Champion??s ATV/UTV Winch Kit has a 3000-lb. rated line pull, a gear reduction ratio of 171:1, plus a mounting channel and remote control to make your experience with this winch even easier. With a tough 1.3-horsepower (12-volt) DC motor, this winch provides efficient pulling power whenever and wherever you need it.
For home, work or play, Champion products are the standard of performance excellence. We make the power that makes your life easier.
We make the power that makes your life easier.
Winches & Hoists
With winches ranging from 2000 to 12,000 pounds and hoists for heavy lifting, you can count on Champion to provide all the pulling and lifting power you need for any situation.
Champion 2000-lb. ATV/UTV Winch Kit
Champion 3000-lb. ATV/UTV Winch Kit
Champion 3500-lb. ATV/UTV Synthetic Rope Winch Kit
Champion 4000-lb. ATV/UTV Winch Kit with Mini-Rocker
Champion 4500-lb. ATV/UTV Wireless Winch Kit
Champion Power Equipment 4500 lb. ATV/ UTV Winch Kit with Universal Hitch Mount
Line Pull (lb.)
2000
3000
3500
4000
4500
4500
Remote Length (ft.)
10.30
10.30
10.30
13.80
13.80
10.30
Gear Ratio
153:1
171:1
171:1
180:1
180:1
166:1
Gear System
Single-Stage Planetary
Three-Stage Planetary
Three-Stage Planetary
Three-Stage Planetary
Three-Stage Planetary
Three-Stage Planetary
Full Load Line Speed (ft/min)
3.30
4.30
3.30
3.30
4.60
3.90
No-Load Line Speed (ft/min)
10.50
8.90
9.80
12.80
12.80
12.80
Clutch Type
Free Spooling
Free Spooling
Free Spooling
Free Spooling
Free Spooling
Free Spooling
Brake System
Dynamic
Dynamic
Dynamic
Dynamic
Dynamic
Dynamic
Rope Material
Galvanized Steel
Galvanized Steel
Synthetic Rope
Galvanized Steel
Galvanized Steel
Galvanized Steel
Rope Length (ft.)
49.00
45.90
50.00
49.00
38.00
52.00
Rope Diameter (in.)
5/32
3/16
3/16
7/32
15/64
1/4
Fairlead Type
4-Way Roller
4-Way Roller
Hawse
4-Way Roller
4-Way Roller
4-Way Roller
Drum Size (in.)
1.2 x 2.9
1.5 x 3.2
1.5 x 3.2
1.7 x 3.1
1.7 x 3.1
2 x 4.9
Bolt Pattern (in.)
3.1
4.9 x 3
4.9 x 3
4.9 x 3
4.9 x 3
6.6 x 3
Mounting Channel
Standard
Standard
Standard
Standard
Standard
Standard
Horsepower (hp)
1.00
1.30
1.20
1.40
1.60
1.60
Max Current at Full Load (A)
120.00
170.00
230.00
220.00
280.00
280.00
Duty Cycle
Intermittent
Intermittent
Intermittent
Intermittent
Intermittent
Intermittent
Motor Type
12V DC (Permanent Magnet)
12V DC (Permanent Magnet)
12V DC (Permanent Magnet)
12V DC (Permanent Magnet)
12V DC (Permanent Magnet)
12V DC (Permanent Magnet)
