Deck For Husqvarna Spindle 532174358 Belt 532180808 Ply 532173436 Bld 532180054

Premium Quality Replacement Part
MOWER DECK SPINDLE PULLEY BLADE BELT KIT
Fits Following Husqvarna Models:
SPINDLE SPEC:
5-29/32″ overall height
Grease fitting on thread end.
Includes bolts, shaft, bearings,blade bolt,washer and dust cap
SPINDLE REPLACEMENT PART NUMBERS:
174356
174358
532174358
587125201
532174356
587125201
539107515
285-108
82-015
NOTE:
Mounting holes do not have thread.Power tool
is needed to install the bolts.It is designed to withstand the vibration.
BELT SPEC:
Width 5/8″
Length 89″
BELT REPLACEMENT PART NUMBERS:
531300771
532180808
532174369
265825
33908
174369
PRIMARY BELT SPEC:
Width 5/8″
Length 91″
PRIMARY BELT REPLACEMENT:
532174368
174368
33907
PULLEY SPEC:
ID: .640 ” DOUBLE HEX
OD: 5 1/8 ”
Double hex ID
PULLEY REPLACEMENT PART NUMBERS:
129861
173436
153535
177865
532129861
532173436
BLADE SPEC:
Width 2.5″
Length 16-3/8″
Thickness 0.203″
Center Hole 5 Point Star
BLADE REPLACEMENT PART NUMBERS:
532180054
532173920
539107519
180054
173920
173921
24679
302408
340222
Order Includes:
3x Spindle Assemblys
3x Pulleys
3x Blades
2 x Belts
