EZGO TXT Shock Absorbers Front and Rear 2 Pairs For 1994-Up Gas & Electric Golf Cart, Replaces OEM Part number # 76418-01, Nivel Part # 5006

???????????????????????: Our EZGO front and rear shocks are designed specifically for EZGO TXT 1994-up Gas and Electric Golf Carts. We include shock bushings and washers with fresh new shocks.
??????????????? ?????????????? ????????????: These front and rear shock absorbers for EZGO TXT are manufactured with larger cylinders to provide more resistance. They help increase the vehicle performance and improve ride quality.
??????? ??????????????????:: These EZGO shocks replace OEM part number # 76418-G01, 70248-G01, 70324-G01, 76419-G01 and Nivel Part # 5006. Shock absorber closed length measures 14 inch and open length measures 17 3/4 inch.
????????? ???? ?????????????? ????????????? If the golf car feels like the front end is ??nose diving??, it is likely that your shocks are bad. The same can be tested for the rear shocks by putting the golf car in reverse and stopping abruptly. Again, if the rear feels like it is going to bottom out. There is likely a problem.
??? ???????? ????????????????: is confident about its products and ensures high quality, so we provide a 1-year warranty to our products. Please feel free to contact us if you have any questions before /after purchasing.
???????? ???????? ???? ???? ???????? ???????? ?????????
FOR EZGO Medalist & TXT models (1994 to present): The serial number and manufacturer’s number can be found on a plate located in the glove box on the passenger’s side of the vehicle. The serial number is either six or seven numbers and does not indicate the model year. The manufacturer’s number does reflect the model year. This series will have one letter and three or four numbers which will include two numbers indicating the last two digits of the year it was manufactured. Newer EZ-GO carts have the words “TXT”, “Freedom TXT”, “RXV” or “Freedom RXV” listed on the side of the cart, located vertically beneath the armrests. Once you have the serial number, then enter your serial number into the top left search box on the EZGO website to verify the make and model of your cart!
?????? ???? ?????????????? ??-??-???? ?????????? ?????? ???????? ?????????????
Follow the steps below
Front Shock Absorber Installation Instructions:
Jack your golf cart upUse 9/16 Wrench to remove lower nut at the bottom of the shock. And then use the same socket to remove the top. Hold the nut with socket in place and twist the shock in counterclockwise motion.Install new shocks with the new shock bushing and washer we include. Insert shock stud into mounting hole and install new bushing and washer. Tighten the nut by holding the nut with 9/16 socket and twist the shock in clockwise motion to install lower section and in counterclockwise motion to install upper section. Tighten shock until the bushings expand to the width of the washers.Repeat the same steps for the other side.
Rear Shock Absorber Installation Instructions:
Jack your golf cart upremove the lower and upper mounting nuts. We include bushings and washers with our shocks. So it is a good idea to replace them at the same time.An easy way to get access to the top of the shock is to remove the rear cover (motor cover) of the vehicle. Hold the top nut with a wrench inside of the frame while twisting the bottom of the shock in a counterclockwise motion.Install new bushings and washers to the shock and reinstall.Attach the upper and lower nuts, tighten the nuts until the bushings expand to the width of the washers.Repeat these steps on the other side.
FRON/REAR SHOCKS FOR CLUB CAR DS GOLF CART
FRONT/REAR SHOCKS FOR CLUB CAR PRECEDENT GOLF CART
FRONT/REAR SHOCKS FOR EZGO TXT GOLF CART
APPLICATION
Club Car DS 1988-2008 Electric and 1997-2008 Gas models.
2004 And Up Gas & Electric Models
1994-Up Gas & Electric Models
