For 17-22 Can-Am Maverick X3 Turbo Winch Plate Bracket + 2″ Rear Receiver Hitch

Fitment
2017-2022 Can-Am Maverick X3
Specifications
2 inch square receiver tube opening and solid all-welded construction for maximum strength and durability
The A-Coat base with Black powder coat finish is resistant to adverse weather conditions and corrosion, ensures an attractive appearance for years to come
Computer-aided design and fatigue stress tested to ensure perfect fit and top towing performance
Compatible with standard 2″ attachments
Easy to install??come with installation instruction
Specifications
No drlling or cutting to install??
Offer a winch mounting Positon on front of Your UTV??
Accurate measurement and design ensure a perfect fit.
Made of solid steel with powder coated black surface to protect ??
Can work with Most winches with US Standard Fairlead(110mm (4 1/4″)/152mm (6″)????
Come with installation instruction??
Package Included
1x Rear Hitch Receiver with necessary hardware
1 x Winch Mounting bracket Kit include necessary hardware
Mounting Holes:
76mm x 169mm (3″ x 6 5/8″)
76mm x 124mm (3″ x 4 7/8″)
Designed to work with the following winches:
The winch mount has a bolt pattern for the majority of aftermarket 3500-6000 lb. winches
KFI: ST17 / A2000 / A2500-R2 / A3000 / U45-R2 / U45w-R2 / SE25 / SE35 / SE45-R2 / SE45w-R2
KFI: AS-50 / AS-50w
WARN:VRX 25 / VRX 25-S / VRX 35 / VRX 35-S
Requires Standard fairlead bracket #101715.
WARN:VRX 45 / VRX 45-S
Requires Wide fairlead bracket #100695.
WARN:AXON 35 / AXON 35-S / AXON 45RC
Requires Standard fairlead bracket #101715.
WARN: AXON 45 / AXON 45-S / AXON 55 / AXON 55-S
Requires Wide fairlead bracket #100695.
WARN:A2000 / A2500 / U2500 / 1.5ci / 2.5ci / 2.5ce / 3.0ci / 3.0ce / 3.0s
WARN:RT15 / RT25 / RT30 / XT15 / XT25 / XT30
WARN:RT40 / XT40
WARN:Vantage 2000-4000lb
WARN:ProVantage 2500-4500lbs
RAMSEY : ATV2500 / ATV3000
SUPERWINCH : Terra25 / Terra35 / Terra 45 / A3500 / LT2000 / LT2500 / LT3000 / LT4000ATV / LT4000UTV
MILE MARKER :PE2.5 / PE 3.5 / VMX2.5 / PE2000 / PE3000 / PE2500 / PE3500
CYCLE COUNTRY :Work Power 1500 and 2500 / Powermax 2500 and 3500
BADLAND 2-Hole Winches : 68146 / 61258 / 61297 / 61840
BADLAND Standard Winches : 68145 / 61604 / 61257 / 61383
BADLAND WIDE Winches : 61384 / 68144 / 61605
CHAMPION 2-Hole Winches : 10028 / 10032 / 12001 / 12002 / 12003 / 12004 / 13001 / 13005 / 100127 / C20049 / C20051 / C20249 / C30045 / C30145
CHAMPION Standard Winches : 10013 / 10018 / 10020 / 10024 / 12053 / 12503 / 12551 / 13004 / 13050 / 13502 / 14001 / 14051 / 14061 / 14560 / 100129 / 100218 / 100243 / 100335
CHAMPION WIDE Winches : 14008 / 14501 / 14551 / 14552 / 40252
KEEPER CORP. TRAKKER :KT2500 / KT3000 / KT2500C / KT3000C / KT4000 / KT4000C
KEEPER CORP. TRAKKER :KT2000
Requires roller fairlead with a 4.875″ bolt pattern; available if needed #ATV-RF.
SMITTYBILT :XRC 2.0
Requires roller fairlead with a 4.875″ bolt pattern; available if needed #ATV-RF.
Listed models come with incorrect ATV roller fairleads.
SMITTYBILT :XRC 3.0 / XRC 4.0
XGEAR: X3000 / X4000
4-Hole Standard (3.00″ x 4.875″ bolt pattern)
VENOM: 2000 / 2500 / 3000 / 3500 / 4000 / 4500 / 5000 (Hardcore Series)
All with 3.00″ x 4.875″ bolt pattern mount-up.
All with 3.00″ x 6.600″ bolt pattern mount-up.
Traveller:1078311
Traveller:1078088 / 1078302
Requries roller fairlead with a 4.875″ bolt pattern; available if needed #ATV-RF
Possibly many others with the below standard mounting patterns, call to confirm.
4-Hole (3.00″ x 4.875″ bolt pattern with rollers that are 4.875″ bolt pattern)
4-Hole WIDE (3.00″ x 6.60″ bolt pattern with rollers that are 6.600″ or 6.000″ bolt pattern)
2-Hole (3.10″ with rollers that are 4.875″ bolt pattern)
QUADBOSS: RP25 / RP35
