Front Winch Mount Plate Kit 2″ Rear Hitch Receiver For Kawasaki Teryx KRX 1000

Fitment
2020-2022 Kawasaki Teryx KRX 1000
Specifications
No drlling or cutting to install.
Offer a winch mounting Positon on front of Your UTV
Accurate measurement and design ensure a perfect fit.
Made of solid steel with powder coated black surface to protect
Can work with Most winches with US Standard Fairlead(Fairlead Bolt Pattern 6″,Mounting Holes:3″ x 6 5/8″(76mm x 169mm) )and our 4500 lb Winches.
Come with installation instruction.
Rear Hitch Receiver:
Easy to install??no drilling or welding necessary.
2 inch square receiver tube opening and solid all-welded Construction for maximum strength and durability
The A-Coat base with Black powder coat finish is resistant to adverse weather conditions and corrosion, ensures an attractive appearance for years to come
Computer-aided design and fatigue stress tested to ensure perfect fit and top towing performance
Compatible with standard 2″ attachments
Come with installation instruction
Package Included
1 x Winch Mounting bracket Kit include necessary hardware.
1 X Rear Hitch Receiver with necessary hardware.
Below winches will mount with no needed additioanl parts:
KFI: ST17 / A2000 / A2500-R2 / A3000 / U45-R2 / U45w-R2 / SE25 / SE35 / SE45-R2 / SE45w-R2
KFI: AS-50 / AS-50w
WARN:VRX 25 / VRX 25-S / VRX 35 / VRX 35-S / VRX 45 / VRX 45-S
WARN:A2000 / A2500 / U2500
WARN:RT15 / RT25 / RT30 / XT15 / XT25 / XT30
WARN:RT40 / XT40
WARN:Vantage 2000-4000lb
WARN:ProVantage 2500-4500lbs
RAMSEY : ATV2500 / ATV3000
SUPERWINCH : Terra25 / Terra35 / Terra 45 / A3500 / LT2000 / LT2500 / LT3000 / LT4000ATV / LT4000UTV
MILE MARKER :PE2.5 / PE 3.5 / VMX2.5 / PE2000 / PE3000 / PE2500 / PE3500 / PE5000
CYCLE COUNTRY : Powermax 2500 / 3500 / 4500
BADLAND: Standard Winches (Click Here for Details)
BADLAND: WIDE Winches (Click Here for Details)
CHAMPION : Standard Winches (Click Here for Details)
CHAMPION : WIDE Winches (Click Here for Details)
KEEPER CORP. TRAKKER :KT3000 / KT2500C / KT3000C / KT4000
SMITTYBILT :XRC 2.0
Requires roller fairlead with a 4.875″ bolt pattern; available if needed #ATV-RF.
Listed models come with incorrect ATV roller fairleads.
SMITTYBILT :XRC 3.0 / XRC 4.0
XGEAR: X3000 / X4000
4-Hole Standard (3.00″ x 4.875″ bolt pattern)
VENOM: 2000 / 2500 / 3000 / 3500 / 4000 (Hardcore Series)
All with 3.00″ x 4.875″ bolt pattern mount-up
All with 3.00″ x 6.600″ bolt pattern mount-up
Traveller: 1078311
Traveller:1078088 / 1078302
Requires roller fairlead with a 4.875″ bolt pattern; available if needed #ATV-RF
Possibly many others with the below standard mounting patterns, call to confirm.
4-Hole (3.00″ x 4.875″ bolt pattern with rollers that are 4.875″ bolt pattern)
4-Hole WIDE (3.00″ x 6.60″ bolt pattern with rollers that are 6.600″ or 6.000″ bolt pattern)
2-Hole (3.10″ with rollers that are 4.875″ bolt pattern)
QUADBOSS: RP25 / RP35
