NEW 12V GENERATOR AND BRUSHES FITS JOHN DEERE UTV GATOR TX TURF G338771 3008369C

THIS ITEM FITS VARIOUS APPLICATIONS BY PART NUMBER. PLEASE CHECK YOUR PART NUMBER TO ENSURE FITMENT.
CLUB CAR GOLF CARTS DS SERIES 1984-2006
CLUB CAR GOLF CARTS FE290 1984-2006
CLUB CAR GOLF CARTS FE350 1984-2006
CLUB CAR UTV 1998-2002
JOHN DEERE UTV GATOR TX TURF KAWASAKI 15.5HP
FITS / Replacement Part Numbers:
CLUB CAR: 1018294-01 101833701 1036785-02
COLUMBIA PARCAR: 3008369A 30083-69B 3008369C 30083-69D 3008369E
HITACHI: 3102201HI1 GSB10701 GSB107-01A GSB10704A
HITACHI SALES: GSB107-04C
MANDO: G096503 G338771 M063686
REDHAWK: MOT2002 MOT-2004 MOT2005
ITEM DESCRIPTION: GENERATOR AND BRUSHES
UNIT TYPE: HITACHI, MANDO, VALEO
VOLTAGE: 12
AMPS: 25
BRUSH LENGTH: 1.024IN / 26MM
BRUSH WIDTH: 0.531IN / 13.5MM
BRUSH HEIGHT: 0.217IN / 5.5MM
LEAD LENGTH: 1.575IN / 40MM
BRUSH QUANTITY: 4
FIELD HSG OD: 113.3MM / 4.461IN
OVERALL LENGTH: 230.3MM / 9.067IN
ROTATION: CW
ROTATION: REVERSIBLE
SHAFT NOTES: THREADED WITH KEYWAY
SHAFT OD: 17MM / 0.669IN
TERMINAL 1 SIZE: M6-1.0
TERMINAL 2 SIZE: M5-0.8
TERMINAL 3 SIZE: M6-1.0
TERMINAL 4 SIZE: M6-1.0
NOTES: 5 TERMINAL MOTOR GENERATOR
WEIGHT: 18.5 LBS / 8.41 KG
