Push Button Starter Switch 12V / 24V Waterproof Push Start Button 50A Heavy Duty Momentary Weatherproof for Horn Engine Car Truck Tractor Boat

1.Feature: This 12 volt push start button is momentary SPST design. The momentary push button switch with a black neoprene cover can prevent water, moisture and dirt.
2.Size: The height of the starter switch is 2.44 inch(without cover), the diameter of the starter button is 1.1 inch. The reqiured mounting hole of the horn button switch is 5/8 inch(0.625 inch).
3.Voltage: The rating of this waterproof engine start button is 50A 12v.
4.Function: The start button is momentary ON/OFF push button switch, normally stay at the OFF position; press, the switch will be turned to ON position; release, the switch will return to the OFF position.
5.Waterproof, Weatherproof & Dustproof: the cover of the button enables the push button starter switch to be used in extreme environment, it is widely used as the horn, ignition and start switch for car, truck, golf cart, rv, atv, utv, lawn tractor, marine, boat, etc.
Momentary Push Button Switch
This starter button is momentary design, SPST 2 pin normal open design, normally stay at OFF position, push: ON, release: OFF.
5/8 Inch Mounting Hole
The mounting hole size of this start switch is 5/8″ (16mm), the height of the start button is about 2.44″ (without cover).
Waterproof Push Button Switch
The push button starter switch will come with a black neoprene cover, which can effectively prevent water, moisture and dirt.
12mm Latching
12mm Latching
12mm Momentary
12mm Momentary
16mm Momentary
19mm Momentary
Size
12mm 12mm 12mm 12mm 16mm 19mm
Function
Latching Latching Momentary Momentary Momentary Momentary
Label Sticker
NO NO NO NO NO NO
16mm Momentary
16mm Latching
19mm Latching
19mm Latching
22mm Momentary
22mm Latching
Size
16mm 16mm 19mm 19mm 22mm 22mm
Function
Momentary Latching Latching Latching Momentary Latching
Label Sticker
NO
?
?
?
NO NO
